產品詳細

產品名稱:high and low furnace Horizontal continuous casting

詳細介紹

parameter:

item unit parameter
mode stream 1;2
material   brass;cupronickel;bronze;copper
width mm 330;450;650
thick mm 12~20
speed mm/min 120~180
power of melting furnace KW 400;500
power of holding furnace KW 170;200
power of tractor KW 7.5; 11
capacity Kg/年 4000000;6500000
max temperature 1350
weight of coil kg 3000;6000;8000
weight of machine kg
dimension mm

functional characteristics:

1.melting and holding temperature furnace are one-body, they are connected by one blind pass, the valve control the liquid-copper into the holding temperature furnace.

2.melting and holding temperature furnace adopt large-area Jet-melt Ditch

3.crystallizer adopt cavity structure, so it has a good cooling effectiveness.

4.holding temperature furnace adopt stepless pressuer-regulator,so the control of temperature is continuous and automatic

5.the driven system of tractor adopt keyless connection and Seamless Gear drive


installation level:

1.the machine is functional ,and the performance parameters is reasonable,the whole line is automatic control.

2.adopt Germany lentz AC servo motor and controlling system;the PLC is Germany siemens,easy maintenance,high reliability,and a wide range of applications

3.the temperature of the furnace is controlled by digital filtering feedforward loop,ensure the temperature of crystallizer and the quality of products.

4.the controlling system has position feedback unit,accoding to the feedback signal ,we can know the position of the strip plate ,then adjust the hydraulic cutter to ensure the length of strip plate .

5.the main electric element are all famous-brand products.

6.PLC.

7.the process parameters can pre-set, the process parameters and key parameters can be displayed ,and it has alarm system,too .
